Roll To Roll Fabric Calender Machine , Two Roll Calender Machine
Product description
Product Details
Product Details:
| Place of Origin: | China |
|---|---|
| Brand Name: | HongYi |
| Certification: | ISO9001/CE |
| Model Number: | 250HYTG |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | negotiation |
| Packaging Details: | Packed in carton firstly,and then reinforced with wooden case for outer packing |
| Delivery Time: | 10 working days after received your payment |
| Payment Terms: | T/T, L/C, Western Union, Western Union, MoneyGram |
| Supply Ability: | 2 set per month |
Roll To Roll Fabric Calender Machine , Two Roll Calender Machine
Description
| Product Name:: | Two Roll Calender Machine | Key Selling Points:: | Multifunctional |
|---|---|---|---|
| Gsm: | 60-1500g/m2 | Thickness: | 3-200mm |
| Name: | Calender Machine | Key Selling Points: | Easy To Operate |
| High Light: |
200mm Fabric Calender Machine,60g/m2 Fabric Calender Machine,fabric two roll calender machine |
||
Roll To Roll Calender Sublimation Printing Machine Fabric Heat Press Transfer Machine
|
Product
|
Parameters
|
|
Specific consumption
|
6kw
|
|
Main power
|
3kw
|
|
Feeding size
|
1.8m
|
|
Transfer span
|
1.6m |
|
Temperature
|
Less than 240℃
|
|
Speed of heating roll
|
5m/min
|
|
Diameter of heating roll
|
271mm
|
|
Voltage
|
220v
|
|
Packing weight
|
220KG
|
|
Packing size
|
212*59*73.5cm
|
Main specifications
Working width ≤5000mm
Product weight (60-1500)gram/㎡
Product thickness (3-200)mm
Surface temp. ≤220℃
Heating method hot oil circulation, electricity heating, direct burning
Oven working width 6.0m 8.0m 10m
Structure
- Single layer,single belt or double-belt structure
- Up and down belts hold the web for entering to get heated and formed.
- High temperrature resistance TEFLON belt with auto correction device.
- Main drive and fan inverter controlling.
