Nowoven Equipment Opening Polyester Fiber High Effective Bale Opener HONGE 2024 New Type HYKB-120

Nowoven Equipment Opening Polyester Fiber High Effective Bale Opener HONGE 2024 New Type HYKB-120

Category：

Bale opener

Product description

The machine is used to pre-open bale-packed fiber, then transfer the fiber to the next working procedure according to a certainty percentage, with electronic weighing system.

Contact now

E-mail

Product Details

Product Details:

Place of Origin:	China
Brand Name:	HONGE
Certification:	ISO9001, CE
Model Number:	HYKB-120

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	Negotitable
Packaging Details:	Wooden package or PE film or naked
Delivery Time:	90 days
Payment Terms:	L/C, T/T

HONGE 2024 New Type HYKB-120 Bale Opener

Description

Capacity::	Max.400kg/h	Working Width:	1200mm
Function:	Used to pre-open bale-packed fiber, then transfer the fiber to the next working procedure according to a certainty percentage, with electronic weighing system	Color:	Customized
High Light:	The bale opener is used to open bale-pack fiber with weighing system，controlled by PLC screen.

HONGE 2024 New Type HYKB-120 Bale Opener

The machine is used to pre-open bale-packed fiber, then transfer the fiber to the next working procedure according to a certainty percentage, with electronic weighing system.
Technical data: working width 1200mm

Production capacity: 400kg/h/set

Control method: photoelectric

Installed power: 15kw

Weighing system: electronic

Structure
1. Machine frame is made of Q235-A armor plate, which is cut with plasma by numerical control, and CNC bending, modularization assembly.
2. The spiked lattice is made of high quality wood with canvas interlining and surrounded with angle steel for supporting.
3. Conveying lattice is made of two sub-section leather lattices in high and low dislocation arrangement.
4. Larger aluminum alloy hoppers, controlled by air cylinders. The maximum opening frequency can reach 3 times per minute, precisely weighing by electronic.

Technical parameters:

Working width	1200mm
Capacity	400kg/h/set
Opening method	Beater
Installed power	15kw

Trade information:

Trade terms	FOB, CIF
Lead time	90 days after deposit.
Payment terms	30% advance payment, 70% paid off before delivery.
Warranty	twelve (12) months after mechanical and electrical commissioning.
After-sale service	The seller is responsible for installation and debugging. The buyer is responsible for the round-trip airplane tickets, accommodation, medical treatment, safety and relative fees. In addition the buyers should assign translator, workers, electrical cable (from machines to control panel and from power to control panel) and tools for installation to cooperate with the work. Installation cost is USD180/Day/engineer and totally installation period is about 30-40 days depending on well cooperation of the buyer.
