HONGE High Speed Nonwoven Machine Carding Machine Single Cylinder Double Doffer

Category：

Nonwoven Carding Machine

Product description

Structure 1. Horizontal feeding lattice is PVC lattice, with pressing roller for evenly feeding;

Contact now

E-mail

Product Details

HONGE High Speed Nonwoven Machine Carding Machine Single Cylinder Double Doffer

Product Details:

Place of Origin:	CHINA
Brand Name:	HongYi
Certification:	CE /ISO9001
Model Number:	HYSL-230

Payment & Shipping Terms:

Minimum Order Quantity:	1 SET
Price:	Negotiation
Packaging Details:	Naked or Wooden case or PE film
Delivery Time:	7 days after receiving the balance
Payment Terms:	T/T, L/C,
Supply Ability:	1 set 60 days

Description

Productivity:	100-600M/MIN	Machine Type:	Single Cylinder Double Doffer
Speed:	Max. 70m/min	High Light:	Nonwoven Carding Machine, 600m/min Nonwoven Carding Machine
Production Rate:	600m/min	Width:	2300mm
Advantage:	High Production Capacity

High speed Nonwoven Carding Machine For Nonwoven Wadding Production Line

Effective Width(mm)		2300
Max. Output(kg/h)		750
Max. Speed (m/min)		100
Structure		Single cylinder and double doffer
Carding Unit	Dia. of working roller,stripping roller	165mm,78mm
	No. of carding groups	5 units
Main cylinder	Dia. of Sub- Cylinder (mm)	1230mm
	No. of working roller (groups)	Single

Structure

1. Horizontal feeding lattice is PVC lattice, with pressing roller for evenly feeding.
2. Four rollers for feeding with diameter 90mm, anti-metal protection device is used at the input part of the machine, which could test the metal and has auto-stop warning.
3. There are five suits of working roller and stripping roller on main cylinder to card fiber completely and form web evenly.
4. Edge-suction system is equipped and the dust particles will be transferred to special dust cage.
5. Walking platforms are placed on two sides of machine for maintenance.
6. Machine safe guard cover is transparent organic glass.

item	value
Marketing Type	New Product 2024
Automatic Grade	Full-automatic
Voltage	380/220V
Power	40kw
Certification	CE/ ISO9001
Working width	Max.2300mm
Production Capacity	800kg/h
Diameter of cylinder	1230mm
Suitable fiber	1.5D-15D*38mm-64mm
Output speed	Maximum 70m/min

• Product: soft wadding
• Product net width : up to 2300mm(or wider dependent on individual requirement )
• Product weight:60-1500g/m2
• Product thickness :3-200mm

Pre-Sales Service
* Inquiry and consulting support
* Sample testing support
* View our factory

After-Sales Service
* Training how to install the machine , training how to use the machine
* Engineers available to service machinery overseas
* Warranty :12 months
* Certificate : ISO9001 CE

Trade information
* Payment terms: 30%deposite by TT, LC , Western Union ,Moneygram 70% as balance paid before delivery LC
* Delivery time: Approx 7 working days after receiving the rest payment
* Package: make, wooden case
* Warrantty:12 months
* After-sales service: we will send 2-3 workers to do the installation and commissioning of the line at the request of the buyer . and the buyer should provide round-trip airplane tickets , accommodation, and allowance, the allowance is 70USD /person/day
* HS code:84490090
* MOQ: 1set
