HONGE NONWOVEN MACHINE WINDING AND CUTTING MACHINE HYXT-280

Category：

Product description

Automatic Cloth Slitting Machine 100 Cotton Canvas Fabric Nonwoven Roll Binding Strip Cutting Machine

Product Details

HONGE NONWOVEN MACHINE WINDING AND CUTTING MACHINE HYXT-280

Product Details:

Payment & Shipping Terms:

Price:	$25,000.00/Sets >=1 Sets
Packaging Details:	Wooden case or naked or PE film
Supply Ability:	1 Set/Sets 60 days

Description:

Features:	Automatic	Max. Workable Width::	2800mm
Machinery Test Report::	CE	Local Service Location:	None
Showroom Location:	None	Video Outgoing-inspection:	Provided
Machinery Test Report:	Not Available	Marketing Type:	Ordinary Product
Warranty Of Core Components:	1 Year	Core Components:	Bearing
Condition:	New	Application:	Cutting fabric or wadding
Automatic Grade:	Automatic	Production Capacity:	100%
Voltage:	380V/220V	Working Width:	Max.2.8m
Warranty:	1 Year	After-sales Service Provided:	Free Spare Parts, Video Technical Support, Online Support, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Engineers Available To Service Machinery Overseas
Product Name:	Winding And Cutting Machine	Cutting Power:	Approx.5kw
Material Capabilities:	Soft Wadding And Stiff Wadding Products	Usage:	To Coil The Soft Wadding In Rolls Or Cut Stiff Wadding Into Sheets.
Working Speed:	1-15m/min	Cutting Type:	Cross Cutter And Vertical Cutter
Safety Device:	Pre-alarming Bell	Port:	Shanghai
Control System:	PLC&touch Screen
High Light:	380V non woven roll cutting machine , 15m/min non woven roll cutting machine , ISO9001 non woven equipment

Automatic Cloth Slitting Machine 100 Cotton Canvas Fabric Nonwoven Roll Binding Strip Cutting Machine

Width:	2.8m
Rotating speed of fabric roll	0-800rpm/min
Fabric roll diameter	300mm(400mm,500mm can also be customized)
Diameter of shaft	37mm
Power	0.75kw
Blade Power	1.5kw
Minimun width of cut strap	2mm
Voltage	380V/220V optional

Working width	2800mm
Working speed	1-15m/min
Power	7.5kw
Suitable product	Needle punched and thermal bonded product
Motor brand	Siemens Beide made in Suzhou
Warranty	1 year for main parts
After-sale service	Online technical service, free spare parts

Payment terms	30% as advance payment by T/T 70% as balance paid off before delivery.
Lead time	90 working days after 30% advance payment.
Package	Naked, wooden case or PE film
HS CODE	84490090
Warranty	The Seller gives a mechanical warranty for all machine parts except from the wearing parts and the problem caused by wrong operation and other man-made factors; the respective warranty period shall be twelve (12) months after mechanical and electrical commissioning.
Installation and commissioning	The installation and start-up will be carried out under the supervision of the Seller’s technicians if the Buyer requests. The Buyer is responsible for providing the necessary number of skilled mechanics, helpers and electrician to assist the whole installation and start-up. The Buyer is in charge of providing round-trip air tickets, appropriate local accommodation, meals, and local transportation for the technicians. The Buyer must assign qualified interpreter during the whole installation, start-up and training. Service cost for installation, start-up and training is USD180 per engineer per day.
