Roll To Roll Fabric Calender Machine
Product description
Product Details
Product Details:
| Place of Origin: | China |
|---|---|
| Brand Name: | HongYi |
| Certification: | ISO9001/CE |
| Model Number: | 250HYTG |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | negotiation |
| Packaging Details: | Packed in carton firstly,and then reinforced with wooden case for outer packing |
| Delivery Time: | 10 working days after received your payment |
| Payment Terms: | T/T, L/C, Western Union, Western Union, MoneyGram |
| Supply Ability: | 2 set per month |
Roll To Roll Fabric Calender Machine
Description
| Printing Area:: | 1.2m/1.6m | Width: | 2-5m |
|---|---|---|---|
| Gsm: | 60-1500g/m2 | Thickness: | 3-200mm |
| Name: | Calender Machine | Key Selling Points: | Easy To Operate |
| High Light: |
1.6m Fabric Calender Machine,OEM Fabric Calender Machine,200mm calender machine textile |
||
3 Set Take Up And Feeding System Digital Textile Roll To Roll Calendering Fabric Heat Transfer Sublimation Machine
|
Diameter of cylinder
|
220mm
|
|
The roll surface
|
Teflosns coating
|
|
Power supply
|
220V/380V
|
|
Heating power
|
7.2KW
|
|
Total power
|
7.3KW
|
|
Speed
|
20-80m/hour
|
|
Temperature range
|
30-250 degree
|
|
Width of Blanket
|
1620mm
|
|
Heat transfer material width
|
1500mm
|
|
Feeding system
|
2sets
|
|
Take up system
|
2sets
|
|
Table size
|
1100*1770*920mm
|
|
Blanket adjustment form
|
Manual adjustment
|
|
Machine weight
|
450kg
|
|
270mmRoller heat transfer machine
|
|
|
Diameter of cylinder
|
270mm
|
|
The roll surface
|
Teflosn coating
|
|
Power supply
|
220V/380V
|
|
Heating power
|
8.2KW
|
|
Total power
|
8.5KW
|
|
Speed
|
20-100m/hour
|
|
Temperature range
|
30-250 degree
|
|
Width of Blanket
|
1620mm
|
|
Heat transfer material width
|
1500mm
|
|
Feeding system
|
2sets
|
|
Take up system
|
2sets
|
|
Table size
|
1100*1770*960mm
|
|
Blanket adjustment form
|
Manual adjustment
|
|
Machine weight
|
500kg
|
|
Blanket deviation alarm
|
for optional
|
|
Automatic cooling
|
for optional
|
|
Machine weight
|
650kg
|
Structure
- Single layer,single belt or double-belt structure
- Up and down belts hold the web for entering to get heated and formed.
- High temperrature resistance TEFLON belt with auto correction device.
- Main drive and fan inverter controlling.
