5m Hongyi Nonwoven fabric Three Roll Calender Machine manufacturer

Category：

Fabric Calender Machine

Product description

Calendering is a finishing process used on cloth and fabrics. A calender is employed, usually to smooth, coat, or thin a material.

Contact now

E-mail

Product Details

Product Details:

Place of Origin:	China
Brand Name:	HONGE
Certification:	ISO9001/CE
Model Number:	HYTG

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	negotiation
Packaging Details:	Packed with PE films.
Delivery Time:	90 working days after received the advance payment
Payment Terms:	T/T, L/C
Supply Ability:	2 set per month

5m Hongyi Nonwoven fabric Three Roll Calender Machine manufacturer

Description

Product Name:	Hongyi Nonwoven Three Roller Calendar Machine	Width:	2-5m
Diameter Of Roller:	480mm	Temp.:	250℃
Key Selling Points:	Easy To Operate	Usage:	Make The Fabric Surface Smooth.
Heating Method:	Conductive Oil	Heating Power:	90Kw
High Light:	calender machine for fabric 1500gsm Nonwoven three roll calender machine 200mm three roll calender machine

Hongyi Nonwoven Three Roll Calender Machine For Fabric

Introduction

Calendering is a finishing process used on cloth and fabrics. A calender is employed, usually to smooth, coat, or thin a material.

With textiles, fabric is passed under rollers at high temperatures and pressures. Calendering is used on fabrics such as to produce its watered effect and also on cambric and some types of sateens.

Nonwoven calendering machine is used to make the surface of nonwoven needle punched fabric or thermal bonded fabric more even and smooth, as well as increase the hardness of fiber by the squeezing of three rollers on the needled fiber web.

Main specifications

Working width: ≤5000mm

Product weight: (60-1500)gram/㎡

Product thickness: (3-200)mm

Surface temp.: ≤250℃

Heating method: hot oil circulation, electricity heating, direct burning

Structure:

1. High quality welded armor plate is made into machine frame.
2. Hot pressing roller chrome plating 0.1mm; Smooth surface finish reaches V12 level. The radial run-out of the full length of each.
3. roller cannot be greater than 0.75mm.
4. Two-roller vertical type, with heat conductive oil heated by electricity.
5. Bottom roller is fixed, and the upper roller are lifted and dropped manually or electrically, the distance range is ≤50mm.
6. Temperature of two rollers is controlled separately, automatically constant temperature.
7. The machine is with protective guide plate, and brake safety rope device.

Trade information

Trade terms	Ex-works, FOB, CFR, CIF
Lead time	90 days
Payment terms	30% as advance payment by T/T, 70% shall be paid off before loading.
Hs code	84490090
Warranty	12 months.
