Fiber Cotton Mixing Machine , Nonwoven Converting Machinery

Category：

Fiber Mixing Machine

Product description

--- working width: 1300mm --- capacity: less than 600kgs/hour --- suitable for different types of fibre blending and mixing.

Contact now

E-mail

Product Details

Product Details:

Place of Origin:	China
Brand Name:	HONGYI
Certification:	ISO9001, CE
Model Number:	HYDC

Payment & Shipping Terms:

Minimum Order Quantity:	2sets
Price:	negotitable
Packaging Details:	PE film
Delivery Time:	30 days.
Payment Terms:	L/C, T/T
Supply Ability:	5 sets per month.

Fiber Cotton Mixing Machine , Nonwoven Converting Machinery

Description

Weight:	According To Size	Certification::	CE/ISO9001 Automatic Cloth Ironing Machine
Raw Material:	Polyester Fiber, Wool, Cotton, Etc.	Color:	Customized
Capacity:	250kg/h-800kg/h	Warranty:	1 Year
Volume:	16m3-30m3
High Light:	30m3 cotton mixing machine , Fiber Cotton Mixing Machine , 250kg/h nonwoven converting machinery

Fiber Cotton Mixing Machine(Nonwoven Machine), Fiber Mixer, Fiber Blending Machine

--- working width: 1300mm
--- capacity: less than 600kgs/hour
--- suitable for different types of fibre blending and mixing.
--- the 2 edges of the beater shaft, there are protection disc to prevent the fiber wrapping onto it.
--- machine frame is made of 8mm preminium carbon steel, tempered and quenched, to eliminate the inner strength.
--- beater diameter: Φ270mm
--- installation power: 8.5 KW
--- even roll and stripping roll 0.75KW-6 motor, Nail lattice and transmission lattice 1.5KW motor, blending roll 5.5KW motor.
--- photocell controls the fibre input volume and the fibre storage volume.
--- nail lattice is inverter controlled, attached with PVC lattice, more durable, transmission lattice is 8 meters long.
--- machine weight: 2000KGS

Features:

1. Photoelectric control during the production process.

2. Fiber density spreads even.

3. The stripper and evener roller are in the independent transmission. This will be with high dependability, easy adjustment and maintenance.

4. The spike lattice with the machine behind control the feeding by Photoelectric to make the blending evener.

Working width	1400mm, 1700mm, 2500mm
Storage volume	16m³-30m³
Capacity	300kg/h, 500kg/h, 800kg/h
Installed power	8.8Kw

Trade information:

Trade terms	FOB, CNF, or CIF
Lead time	90 days after deposit.
Payment terms	30% advance payment, 70% paid off before delivery.
Warranty	twelve (12) months after mechanical and electrical commissioning.
After-sale service	The seller is responsible for installation and debugging. The buyer is responsible for the round-trip airplane tickets, accommodation, medical treatment, safety and relative fees. In addition the buyers should assign translator, workers, electrical cable (from machines to control panel and from power to control panel) and tools for installation to cooperate with the work. Installation cost is USD180/Day/engineer and totally installation period is about 30-40 days depending on well cooperation of the buyer.
